| DHW-P TYPE 1+1 PROVIDED INFRA-RED HEATER& PLASTIC BOTTLE BLOWER |
 |
|
|
|
|
| Product description |
| |
| coalition mould |
KN |
60 |
| underlay lifting height |
mm |
120&210 |
| max.mould size (l*h) |
mm |
390×345 |
| mould ply |
mm |
120-160&220-270 |
| space between mould |
mm |
120-170 |
| max.lifting height |
mm |
340 |
| pressure for working |
Mpa |
0.8-1.0 |
| pressure for blowing |
Mpa |
0.8-2.8 |
| max.container volume |
Lifre |
5.5 |
| machine size(L*X*H) |
Mm |
1460×580×1800 |
| packing size(L*X*H) |
mm |
1660×770×2120 |
| weight |
Kg |
600 |
| output |
Psc/hr |
300-650 |
DHP-P Infrared heater |
| temperature |
class |
6-10 |
| heating time |
s |
90-200 |
| voltage |
v |
220 |
| frequency |
Hz |
50 |
| heating power |
kw |
6.3-10.3 |
| power |
kw |
≤5 |
| machine size(L*X*H) |
mm |
1350×550×1150 |
| packing size(L*X*H) |
mm |
1550×750×1350 |
| weight |
Kg |
250 |
|
| |
|
|
|
